  • Product description: 9Guage Black Vinyl Galvanized Chain Link Fence
  • INQUIRY

Chain link fence



Chain link fence also known by some as cyclone fence, is one of the most popular choices of fence for both light residential to heavy commercial fence applications. Chain link fence is one of the most practical styles of fence, relatively easy to install, and very cost effective.


Chain link fence is most commonly available galvanized which is silver in color. We also carry colored chain link fence fabric, framework (posts and rail), colored fence fittings, gates (swing and slide), and gate hardware for all fencing applications from standard residential to light commercial, to heavy commercial and industrial fence applications. Colored fence fittings and chain link framework (posts and rails) are either powder coated, or coated in a heavy vinyl coated (PVC) material in standard colors such as black, dark brown, and dark green. White is also available as special order fencing. It is not uncommon to combine the two and stretch a vinyl coated chain link fabric on a galvanized frame. All aluminum chain link fabric, aluminum tubing, and aluminum chain link fittings and gates are also available for special applications and is preferred by many near saltwater.


Chain link fence Common Applications:

•Budget boundaries
•Medium Security
•Schools
•Parks
•Recreational grounds

KxK = Knuckle x Knuckle, chain link top and bottoms are bent over.
KxB or KxT= Knuckle x Barb or Knuckle x Twist, chain link is twisted at one end to form two barbs.


Fabric
Galvanized
11-1/2 gauge

Size
(Mesh x Gauge x Height)

Ends

Weight
(Per 50' Roll)

2-1/4 x 11-1/2 x 36

KxK

60 lbs

2-1/4 x 11-1/2 x 42

KxK

71 lbs

2-1/4 x 11-1/2 x 48

KxK

84 lbs

2-1/4 x 11-1/2 x 60

KxK

101 lbs

2-1/4 x 11-1/2 x 72

KxB

121 lbs

Chain link fence Size Column: mesh size in inches x gauge of wire x height of fence in inches.

Fabric
Vinyl Extruded
9 gauge

Size
(2" mesh, 9 gauge)

Type

Weight
Per 50'

36" high

KxK

53 lbs

42" high

KxK

63 lbs

48" high

KxK

70 lbs

60" high

KxK

88 lbs

72" high

KxB

105 lbs

84" high

KxB

123 lbs

96" high

KxB

140 lbs

120" high

KxB

173 lbs

144" high

KxB

208 lbs
