Double Wire Fence/Prestige Mesh Fence
Post Section:
This system usually choose Square Post ,Rectangular Post as follows,
To2400mmhigh:60mmx40mm
To3800mmhigh:80mmx40mm
To5000mmhigh:100mmx50mm
To6000mmhigh:120mmx60mm
with plastic caps or Roofing rain hat
Surface Processing:Hot dipped galvanized, galvanized and powder coated
Fastenings:The panels and posts are jointed together with bolts or rivets, using the steel flat bar or special steel clamps, all nuts are self-locking.
Standard colors: RAL 6005 green, 9005 black, 5010 blue, 3000 red, 9010 white
Specification of Double Wire Fence:
|
Double Wire Fence |
|||||
|
Height x Width panel mm |
Mesh size mm |
Wire diameter |
Post of height mm |
||
|
Wire Dia. mm |
Wire Dia. mm |
Wire Dia. mm |
|||
|
630×2500 |
50×200 |
8×2+6 |
6×2+5 |
6×2+4 |
1100 |
|
830×2500 |
50×200 |
8×2+6 |
6×2+5 |
6×2+4 |
1300 |
|
1030×2500 |
50×200 |
8×2+6 |
6×2+5 |
6×2+4 |
1500 |
|
1230×2500 |
50×200 |
8×2+6 |
6×2+5 |
6×2+4 |
1700 |
|
1430×2500 |
50×200 |
8×2+6 |
6×2+5 |
6×2+4 |
1900 |
|
1630×2500 |
50×200 |
8×2+6 |
6×2+5 |
6×2+4 |
2100 |
|
1830×2500 |
50×200 |
8×2+6 |
6×2+5 |
6×2+4 |
2400 |
|
2030×2500 |
50×200 |
8×2+6 |
6×2+5 |
6×2+4 |
2600 |
|
2230×2500 |
50×200 |
8×2+6 |
6×2+5 |
6×2+4 |
2800 |
|
2430×2500 |
50×200 |
8×2+6 |
6×2+5 |
6×2+4 |
3000 |
